Mechanical keyboard Epomaker HE75 V2 Jade HE Switch black-creamy

Apraksts

Epomaker HE75 V2 Jade HE Switch mechanical keyboard

Performance and features for gamers

EPOMAKER HE75 V2 is a 75% keyboard with Hall Effect switches, offering an 8000 Hz polling rate (USB and 2.4 GHz), a 128 kHz scan rate, and very low latency – 0.1 ms wired and 0.58 ms in 2.4 GHz mode. The switches allow adjustment of the actuation point from 0.1 to 3.5 mm with accuracy up to 0.005 mm and support Rapid Trigger and SOCD functions. The keyboard uses factory-lubed EPOMAKER Creamy Jade HE switches with an operating force of 30–55 gf and a total travel of 3.5 mm. Thanks to this, it works well both in dynamic games and during everyday work.

Construction, comfort, and customization

The HE75 V2 model is equipped with 80 keys and an interchangeable knob that can be replaced with two additional keys. The gasket construction with a 5-layer sound-dampening system (foam, PET layer, sponge, and silicone) provides a softer typing feel and a distinctive, deep sound. The keyboard has matte, transparent keycaps made of PC in Cherry profile and individually configurable RGB lighting with south-facing LEDs and an additional front light strip. Two-stage feet allow the tilt angle to be set to 5.8°, 9°, or 12°, improving user ergonomics.

Connectivity and specifications

The keyboard supports three connection modes – wired, Bluetooth, and 2.4 GHz – and is compatible with Windows, macOS, and Android. The built-in 8000 mAh battery provides up to 20 hours of runtime with RGB backlighting enabled. The model uses an ABS housing, FR4 plate, plate-mounted stabilizers, and hot-swap compatible with selected Hall Effect switches. Settings, macros, and advanced functions can be configured using EPOMAKER 3.0 (V4) software, which works online and offline.

Technical Specifications

Brand EPOMAKER Model HE75 V2 Layout 75%, ANSI US, QWERTY Number of keys 80 keys + 1 knob (can be replaced with 2 keys) Structure Gasket Mount Hot-swappable Yes, compatible with selected Hall Effect switches Plate material FR4 Housing material ABS Flex-Cut No Stabilizer type Plate-mounted stabilizers Keycap profile Cherry Keycap material PC, matte, transparent Keycap manufacturing technology Print RGB direction South-facing, individually adjustable RGB backlighting and front RGB strip Polling rate 8000 Hz (USB / 2.4 GHz), 125 Hz (Bluetooth) Scan rate 128 kHz (full keyboard), 16 kHz per key Latency 0.1 ms (USB), 0.58 ms (2.4 GHz), 15 ms (Bluetooth) Battery capacity 8000 mAh Compatibility Windows, macOS, Android Connectivity Wired USB, 2.4 GHz, Bluetooth Software EPOMAKER 3.0 (EPOMAKER V4) Sound dampening (5 layers) Sandwich Foam
PET Sound Enhancement Pad
Sponge
Bottom Silicone Front height 1.9 cm Rear height 3.29 cm Tilt angle 5.8°, 9°, or 12° (2-stage feet) Keyboard dimensions 324 × 132 × 43 mm Keyboard weight about 1 kg Color black-cream (Black-Creamy)

Switches

Name EPOMAKER Creamy Jade HE Switch Type Magnetic Hall Effect Material Stem: POM, Top housing: PC, Bottom housing: PA66 Factory lubrication Yes Initial force 30 gf (min.) Bottom-out force 55 gf (max.) Actuation point Adjustable from 0.1 to 3.5 ± 0.1 mm (in 0.005 mm increments) Total travel 3.5 ± 0.1 mm Magnetic flux (initial) 95 ± 15 GS Magnetic flux (bottom-out) 580 ± 50 GS Light diffuser Yes, transparent acrylic light diffuser
